LIAN LI O11-DYNAMIC-MINI MID TOWER ATX CABINET (WHITE) (G99-011DMI-W-IN)
Features
Think Big. Build Small.
O11D MINI adding to the O11 Dynamic series, the classic and mordern looking. A case that would accommodate the maximum number of water-cooling configurations without being oversized. With a modular back panel design, the user has the option to choose from 3 slots/ 5 slots/ 7 slots I/O shield to optimize the case to the configuration of user’s choice. Supports mini-ITX, micro-ATX, ATX, motherboard sizes. and up to 9 fans to cool the chassis.
Key Features
-
Space for ATX-, Micro-ATX- or Mini-ITX-form factor
motherboards -
A wide range of configuration options for radiators and fans at
the top, bottom, and beside the motherboard -
three different pump stands are provided to accommodate
different water cooling scenarios. -
Can hold up to 4 storage drives
Support 2 x USB 3.0, 1 x USB 3.1 TYPE-C. 1 x HD Audio
Specifications
| Product Name | O11 Dynamic MINI |
| MODEL | O11D Mini-W |
| COLOR | White |
| DIMENSIONS | (D)420mm X (W)269.5mm X (H)380mm |
| MOTHERBOARD | ATX/ Micro-ATX/ Mini-ITX |
| PSU | SFX/ SFX-L |
| MATERIAL |
0.8mm SPCC (body) 1mm SPCC (interior, back panel) 4 mm Tempered Glass 2mm Aluminum (top and left panel) |
| FAN SUPPORT |
Top: 3x 120mm or 2x 140mm Side: 2x 120mm or 2x 140mm Bottom: 3x 120mm or 2x 140mm Rear: 1x 120mm |
| RADIATOR SUPPORT |
Top: 360mm or 280mm or 240mm radiator Side: 240mm or 280mm radiator Bottom: 360 or 280mm or 240mm radiator |
| GPU LENGTH CLEARANCE | 395mm |
| CPU COOLER HEIGHT CLEARANCE | 170mm |
| VGA Length | 370mm |
| DRIVES | Right side 2 x 2.5″ SSD + back plate 2 x 3.5″ HDD (or SSD) |
| EXPANSION SLOTS | 3 or 5 or 7 slots (depends on back panel) |
| IO PORTS | 2 x USB 3.0, 1 x USB 3.1 TYPE-C, 1 x HD Audio, Power Button |
| DUST FILTERS | 1 x Top, 1 x Bottom, 2 x Side |
| Warranty | 1 Year |
| Note | ***Features, Price and Specifications are subject to change without notice. |
|
Brand |
Lian Li |
|
Radiator Support |
360mm |
|
Motherboard Support |
ATX, Micro ATX, Mini ITX |
|
Case Type |
Mid Tower |
|
Color |
White |
|
Warranty |
1 Year |
