Asus Mini PC PL64-B-S5052MN–90MR00V1-M001M0 I5-1235U – (8 GB Ram | 256 GB Nvme SSD | Windows 11 | Prebuilt Mini PC)

About this item

  • Processor: Intel® Core i5
  • Graphics Card: Intel® Iris xe Graphics
  • RAM Memory Installed Size: 8GB DDR5
  • Storage Disk Size: 256GB Nvme SSD
  • Warranty: 1 Year
  • Pan India Sales & Support

Original price was: ₹80,000.Current price is: ₹62,647.

Incl Tax

Incl Tax

Availability: in stock

Buy Now
Product Page Icons

Chat | +919082468103

Authorized Dealer

ASUS Mini PC PL64-B-S5052MN | Intel Core i5-1235U | 8GB RAM | 256GB NVMe SSD | Windows 11 | Prebuilt Mini PC

Introducing ASUS PL Series Mini PCs

ASUS PL series mini PCs are designed mainly for indoor industrial applications. PL series mini PCs are subjected to strict testing standards, offer legacy connectivity and long product life cycles to cater to a diverse range of uses.

Why use ASUS PL64?

  • Performance – Fanless design and 15-watt CPU support in a compact 0.81-liter chassis
  • Reliability – Subjected to stringent 24/7 testing and passed the MIL-STD-810H standard to ensure long-lasting dependability
  • Longevity – Guaranteed 48-month product life cycle, with additional long-term support to extend product life.

Digital Signage – Advantages

  • Compact 200 x 120 x 34 mm dimensions, ideal for digital signage
  • Stunning 4K resolution output
  • Triple display support via HDMI
  • EDID emulation: Ensures video output is suitable for the display
  • Virtual display: Efficient remote device management without a monitor

12th Gen Intel® Core™ Processors

ASUS Mini PC PL64 is powered by 12th Generation Intel® Core™ Processors featuring a new hybrid processor design. This new core design enables PL64 to process multiple tasks simultaneously in the most efficient way possible.

With the whole new design CPU, PL64 can deliver superior performance for you to you process intensive business operations more efficiently.

Fanless Chassis Design with TDP 15W Support

ASUS Mini PC PL64 employs a new fanless design that lowers operational noise and minimizes dust ingress into the chassis, prolonging product life. The fanless design and 15-watt CPU support make PL64 ideal for industrial applications where reliability, durability, and low noise are paramount.

Optimized Cooling Design

Designed to operate at up to 50° C ambient temperature

The cooling system of Mini PC PL64 is connected to a heatsink for efficient heat dissipation to ensure optimal performance even when deployed in hot environments reaching up to 50° C

Compact Size with Metal Chassis

ASUS Mini PC PL64 measuring just 199.7 x 119.7 x 33.9 mm size and 0.81-liter chassis. The compact size makes PL64 suitable for digital signage, kiosk or any other space-constraint environments. Its metal chassis also makes PL64 more durable and perfect for industrial scenarios.

Advanced Output Management

EDID Emulation

Mini PC PL64 features Extended Display Identification Data (EDID) emulation and retains signage format so content being displayed remains unaffected even in the event of a temporary loss of power or connectivity issues, making it ideal for digital.

Virtual Display

PL64 can create virtual screens without a connected display. Virtual Display technology provides access to the system via a remote desktop, without affecting content that’s currently being displayed, allowing an administrator to manage the system offsite.

Productivity

4K Resolution & Triple Display Support

Mini PC PL64 is equipped with Intel® Iris® Xe Graphics (i5/i7) or Intel® UHD Graphics (i3/Celeron®) to display videos and images in stunning 4K resolution. PL64 can support up to three 4K displays simultaneously via HDMI®, so it’s well suited for digital signage, billboard, and advertising applications.

Specifications

Model NamePL64 (PL64-B-S5052MN–90MR00V1-M001M0)
CPU i5-1235U
RAM8GB DDR4 3200
Storage256GB NVMe SSD
Processor GraphicsIntel® Iris xe Graphics
Wireless Data NetworkIntel® Wi-Fi 6 (Gig+) 2×2 + Bluetooth® 5.2 Wireless Card
LAN10/100/1000 Mbps, 1G Intel® LAN
AudioRealtek® ALC3251 HD Audio CODEC
Front(Side) I/O Ports3 x USB 3.2 Gen2 Type-A(5V/0.9A, 10Gbps)
2 x USB 3.2 Gen1 Type-A(5V/0.9A, 5Gbps)(side)
2 x COM (RJ50; support RS232, 422, 485 )
1 x Audio Jack(Line out/Mic in/Headphone out)
1 x Kensington Lock(side)
Back I/O Ports3 x HDMI 2.1 (Up to 4K@60Hz)
1 x 2.5G RJ45 LAN
1 x RJ45 LAN
1 x EDID reset
2 x Antenna Jack
1 x DC-in
Power Supply19Vdc, 3.42A, 65W Power Adapter
Dimensions (W x D x H)199.7mm x 119.7mm x 33.9mm
Weight1.0KG
ColorECO Black, non-logo
AccessoriesAC Adapter
Power Cord
Screw Pack
User Manual
Warranty Card
OS SupportedWindows 11
Warranty3 Years
Ram Size

8GB

Storage

256 GB

Memory Type

DDR4

Processor

core i3

Processor Graphics

Integrated

Warranty

1 Year
