Intel i5-11600K Processor
Built employing a 14nm process, this 11th-generation desktop processor features a base clock frequency of three .9 GHz and a 4.9 GHz turbo frequency with 12MB of cache, six cores, and twelve threads for fast and reliable performance.
The Intel Core i5-11600K 3.9 GHz Six-Core LGA 1200 Processor in your computing system helps power up your productivity, gaming, and content creation experiences.
This processor also includes support for PCI Express 4.0 and dual-channel DDR4 memory at 3200 MHz to assist run and multitasking various demanding applications and games using technologies such as built-in AI acceleration.
The Intel Core i5-11600K may be a fantastic processor for gaming, with top-notch performance and support for PCIe 4.0, which maximizes the speed of supported next-gen SSDs.
Specifications
| Product Collection | 11th Generation Intel® Core™ i5 Processors |
| Code Name | Products formerly Rocket Lake |
| Vertical Segment | Desktop |
| Processor Number | i5-11600K |
| Lithography | 14 nm |
| Total Cores | 6 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.90 GHz |
| Intel® Turbo Boost Technology 2.0 Frequency | 4.90 GHz |
| Processor Base Frequency | 3.90 GHz |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| TDP | 125 W |
| Configurable TDP-down Base Frequency | 3.60 GHz |
| Configurable TDP-down | 95 W |
| Max Memory Size | 128 GB |
| Memory Types | DDR4-3200 |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 50 GB/s |
| ECC Memory Supported | No |
| GPU Name | Intel® UHD Graphics 750 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.30 GHz |
| Graphics Video Max Memory | 64 GB |
| Execution Units | 32 |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI) | 4096×2160@60Hz |
| Max Resolution (DP) | 5120×3200@60Hz |
| Max Resolution (eDP) | 5120×3200@60Hz |
| DirectX Support | 12.1 |
| OpenGL Support | 4.5 |
| OpenCL Support | 3.0 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D | Yes |
| Intel® Clear Video HD | Yes |
| Intel® Clear Video | Yes |
| # of Displays Supported | 3 |
| Device ID | 0x4C8A |
| Scalability | 1S Only |
| PCI Express Revision | 4.0 |
| PCIe Configurations | Up to 1×16+1×4, 2×8+1×4, 1×8+3×4 |
| Max # of PCIe Lanes | 20 |
| Sockets Supported | FCLGA1200 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2019A |
| Tjunction | 100 °C |
| Package Size | 37.5 mm x 37.5 mm |
| Intel® GNA | 2.0 |
| Intel® DL Boost | Yes |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Max 3.0 | No |
| Intel® Turbo Boost 2.0 | Yes |
| Intel® Hyper-Threading | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, SSE4.2, AVX2, AVX-512 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology | Yes |
| Intel vPro® Eligibility | Intel vPro® Platform |
| Intel® Secure Key | Yes |
| Intel® AES-NI | Yes |
| Intel® SGX | No |
| Intel® OS Guard | Yes |
| Intel® TXT | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Intel® SIPP | Yes |
| Intel® VT-x | Yes |
| Intel® VT-d | Yes |
| Intel® EPT | Yes |
