Intel i7-13700KF Processor
The Intel Core i7-13700KF is a desktop processor from Intel’s 13th generation of Core processors, also known as Alder Lake. Here are some key details about the i7-13700KF:
Architecture: The i7-13700KF is based on the hybrid architecture of Alder Lake. It combines high-performance cores with high-efficiency cores, providing improved power efficiency and performance.
Cores and Threads: The i7-13700KF features eight high-performance cores and eight high-efficiency cores, for a total of 16 cores. It supports up to 20 threads, allowing it to handle multiple tasks simultaneously.
Clock Speed: The base clock speed of the i7-13700KF is not known as it is a hypothetical processor at the time of my knowledge cutoff. The actual clock speeds would be determined by Intel based on the specific model.
Cache: The processor is expected to have a significant amount of cache, including both shared cache and individual cache per core. The exact cache specifications would be determined by Intel for this processor.
Graphics: The “KF” in the i7-13700KF model name indicates that it does not include integrated graphics. You would need a dedicated graphics card to display visuals if you opt for the i7-13700KF.
TDP: The thermal design power (TDP) of the i7-13700KF is not known as it is a hypothetical processor. The actual TDP would be determined by Intel for this specific model.
The i7-13700KF is expected to offer high-performance capabilities suitable for demanding tasks such as gaming, content creation, and heavy multitasking. However, please note that the information provided is based on assumptions and speculation, as the i7-13700KF has not been officially released as of my knowledge cutoff in September 2021. It is recommended to refer to official Intel sources or reliable tech news for the most accurate and up-to-date information about the i7-13700KF or any other Intel processors.
Specifications
Product Collection | 13th Generation Intel® Core™ i7 Processors |
Code Name | Products formerly Raptor Lake |
Vertical Segment | Desktop |
Processor Number | i7-13700KF |
Lithography | Intel 7 |
Total Cores | 16 |
# of Performance-cores | 8 |
# of Efficient-cores | 8 |
Total Threads | 24 |
Max Turbo Frequency | 5.40 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency | 5.40 GHz |
Performance-core Max Turbo Frequency | 5.30 GHz |
Efficient-core Max Turbo Frequency | 4.20 GHz |
Performance-core Base Frequency | 3.40 GHz |
Efficient-core Base Frequency | 2.50 GHz |
Cache | 30 MB Intel® Smart Cache |
Total L2 Cache | 24 MB |
Processor Base Power | 125 W |
Maximum Turbo Power | 253 W |
Marketing Status | Launched |
Launch Date | Q4’22 |
Embedded Options Available | No |
Use Conditions | PC/Client/Tablet |
Datasheet | View now |
Max Memory Size (dependent on memory type) | 192 GB |
Memory Types | Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 89.6 GB/s |
Direct Media Interface (DMI) Revision | 4.0 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations | Up to 1×16+4, 2×8+4 |
Max # of PCI Express Lanes | 20 |
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2020A |
TJUNCTION | 100°C |
Package Size | 45.0 mm x 37.5 mm |
Max Operating Temperature | 100 °C |
Intel® Gaussian & Neural Accelerator | 3.0 |
Intel® Thread Director | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Hyper-Threading Technology | Yes |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel® Standard Manageability (ISM) | Yes |
Intel® Secure Key | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® AES New Instructions | Yes |
Intel® OS Guard | Yes |
Execute Disable Bit | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
