HARDWARE
Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation, ensuring even high-end processors to run in full speed.
M.2 Shield Frozr
Keeps M.2 SSDs safe while preventing throttling, making them run faster.
Heavy Plated VRM Heatsink
The VRM heatsink covers the upperMOS and helps dissipate the heat.
7W/mK Thermal Pad &Additional Choke Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performcance.
PERFORMANCE
LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 256GB/s.
SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.
Brand |
MSI |
Compaitability |
Intel |
CPU Socket Type |
LGA 1700 |
CPU Type Support |
Windows 10 build 21H1 and Windows 11 |
Chipset |
Intel B760 |
Number of Memory Slots |
4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
Maximum Memory Supported |
256GB |
Memory Type Supported |
1R 7000MHz |
Channel Supported |
Dual Channel |
Expansion Slots |
2x PCIe x16 slots |
Storage Supported |
3 x M.2 slots and 4x SATA 6Gb/s ports |
USB Ports |
Type A |
Audio Type Supported |
7.1-Channel High Definition Audio |
HDMI |
1 x HDMI |
Form Factor |
Micro ATX |
LED Lighting |
RGB |
OPERATING / SYSTEM |
Support for Windows® 11 64-bit, Windows® 10 64-bit |
Internal slots |
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 5x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
Back planel slots |
USB 2.0 DisplayPort 1.4 USB 3.2 Gen 2 10Gbps Type-A 2.5G LAN Port Wi-Fi / Bluetooth Antenna HD Audio Connectors HDMI™ 2.1 Port USB 3.2 Gen 2×2 20Gbps Type-C Optical S/PDIF OUT |
