MSI MAG Z790 Tomahawk MAX WIFI DDR5 Motherboard
-
- Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
-
- Supports DDR5 Memory, up to 7800+(OC) MHz
-
- Enhanced Power Design: 16+1+1 Mirrored Power Arrangement, dual 8-pin CPU power connectors, Core Boost, Memory Boost
-
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 M.2, USB 3.2 Gen 2×2
-
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
-
- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
-
- High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material
The MSI MAG Z790 Tomahawk MAX WIFI DDR5 Motherboard is a top-tier choice for gamers and PC enthusiasts looking for a robust and feature-rich foundation for their builds. It supports the latest 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® processors with its LGA1700 socket. This motherboard is designed to handle high-performance tasks with ease, thanks to its support for DDR5 memory, allowing for speeds up to 7800+ MHz (OC) and a maximum capacity of 192 GB.
One of the standout features of this motherboard is its advanced connectivity options. It includes Wi-Fi 7 and a 2.5G LAN for fast and reliable internet connections. The motherboard also supports PCIe 5.0, providing the latest in high-speed data transfer capabilities. For storage, it offers four M.2 slots and eight SATA ports, ensuring ample space for all your storage needs.
The MSI MAG Z790 Tomahawk MAX WIFI is also equipped with a premium thermal solution, including an extended heatsink design and M.2 Shield Frozr, which helps keep your system cool even under heavy loads. The audio experience is enhanced with Audio Boost 5, featuring the Realtek ALC4080 audio processor and high-quality audio capacitors for studio-grade sound quality.
The MSI MAG Z790 Tomahawk MAX WIFI is also equipped with a premium thermal solution, including an extended heatsink design and M.2 Shield Frozr, which helps keep your system cool even under heavy loads. The audio experience is enhanced with Audio Boost 5, featuring the Realtek ALC4080 audio processor and high-quality audio capacitors for studio-grade sound quality.
Brand |
MSI |
CPU Socket Type |
14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors |
Chipset |
Intel Z790 |
Memory Support |
7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz |
Number of Memory Slots |
4x DDR5 UDIMM, Maximum Memory Capacity 192GB |
Maximum Memory Supported |
192GB |
Channel Supported |
Dual Channel |
Expansion Slots |
2x PCI-E x16 slot |
Storage Supported |
8x SATA 6Gb/s |
HDMI |
1 x HDMI |
INTERNAL I/O |
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 1x USB4 card connector (JTBT_U4_1, supports RTD3) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
BACK PANEL PORTS |
Display Port USB 3.2 Gen 1 5 Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-A) 2.5G LAN Wi-Fi / Bluetooth Audio Connectors HDMI™ Clear CMOS Flash BIOS USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) USB 3.2 Gen 2×2 20Gbps (Type-C) |
OS Supported |
Windows® 10 64-bit, Windows® 11 64-bit |
Warranty |
3 Years |
