Lian Li V3000 Plus Atx Full Tower Cabinet (V3000-PLUS)
- Full tower chassis with 3 modes: Standard/ Rotate/ Dual-System
- Capability to support an EEB motherboard and an ITX motherboard
- Supports up to 4×480 + 1×360 radiators and a maximum of 17 fans
- Two reservoir plates accommodate large D5/ DDC pump
- Stores up to 16 storage drives at drive cages and trays
- Modular removable brackets offer flexibility for builds
- Cable management friendly with 7 Velcro straps
|
PRODUCT NAME |
LIAN LI V3000 PLUS |
|---|---|
|
MODEL |
V3000PX |
|
DIMENSIONS |
(D) 678.5mm x (W) 279mm x (H) 674mm |
|
COLOR |
Black |
|
MATERIALS |
Aluminum Steel 4.0mm Dark Tinted Tempered Glass (right side) 4.0mm Tinted Tempered Glass (left side) |
|
MOTHERBOARD SUPPORT |
Standard EEB/E-ATX/ATX/Micro-ATX/Mini-ITX Rotated EEB/E-ATX/ATX/Micro-ATX/Mini-ITX Dual System System 1 – EEB/E-ATX/ATX/Micro-ATX/Mini-ITX System 2 – Mini-ITX |
|
FAN SUPPORT |
Standard Front：4 x 120mm or 3 x 140mm Top：4 x 120mm or 3 x 140mm or 2 x 200mm Above PSU Chamber：3 x 120mm or 3 x 140mm Bottom side：4 x 120mm or 3 x 140mm Rear: 1 x 120mm or 1 x 140mm Rotated Front：4 x 120mm or 3 x 140mm Top：4 x 120mm or 3 x 140mm or 2 x 200mm Bottom side：4 x 120mm or 3 x 140mm Rear: 3 x 120mm or 2 x 140mm Dual System Front：4 x 120mm or 3 x 140mm Top：4 x 120mm or 3 x 140mm or 2 x 200mm Above PSU Chamber：2 x 120mm or 2 x 140mm Bottom side：4 x 120mm or 3 x 140mm (without System 2 GPU) Rear: 1 x 120mm or 1 x 140mm |
|
RADIATOR SUPPORT |
Standard Front：480mm or 420mm Top：480mm or 420mm Above PSU Chamber：360mm or 420mm Bottom side：480mm or 420mm Rotated Front：480mm or 420mm Top：480mm or 420mm Bottom side：480mm or 420mm Rear: 360mm or 280mm Dual System Front：480mm or 420mm Top：480mm Above PSU Chamber：240mm or 280mm Bottom side：480mm or 420mm (without System 2 GPU) |
|
PSU SUPPORT |
System 1 – ATX (Max 220mm) System 2 – SFX-L/SFX |
|
GPU LENGTH CLEARANCE |
Standard Max 589mm Rotated Max 358mm Dual System System 1 – Max 589mm System 2 – Max 320mm (Width max 125mm) |
|
CPU COOLER HEIGHT CLEARANCE |
System 1 – Max 198mm System 2 – Max 80mm |
|
PRODUCT DRIVE SUPPORTNAME |
Drive Cage：8 × 2.5” SSD or 8 × 3.5” HDD Side：4 × 2.5” SSD Behind MB tray: 4 × 2.5” SSD |
|
EXPANSION SLOT |
System 1 – 8 System 2 – 3 (at PSU shroud, with optional riser cable) |
|
I/O PORTS |
System 1 1 x Power Button 1 x Reset Button 1 x Light Color Button (C) 1 x Light Mode Button (M) 2 x USB 3.0 1 x USB Type C 1 x Audio System 2 1 x Power Button 1 x Reset Button 2 x USB 3.0 1 x USB Type C 1 x Audio |
|
DUST FILTER |
1 x Bottom |
|
WARRANTY |
1 year |
|
NOTE** |
**Prices, Specifications & Features are subject to change without notice |
|
Brand |
Lian Li |
|
Radiator Support |
480mm |
|
Motherboard Support |
ATX, EATX, EEB, Micro ATX, Mini ITX |
|
Case Type |
Full Tower |
|
Color |
Black |
|
Warranty |
1 Year |
