COOLER MASTER MASTERAIR MA624 STEALTH




  • Premium Aluminum Black Top Cover
  • Dual Tower Heat Sink
  • 6 Heat Pipes with Nickel Plated Base
  • Dual SickleFlow 140 Fan
  • 3rd 120 mm fan for RAM Clearance
  • Easy Mounting System

8,699.00


100% Genuine Brands

Big Saving

Fast Ship & Track

25 year of service


Manufacturer Warranty



Compatibility & Clearance

COMPATIBILITY & CLEARANCE

Optimized design for graphic cards’ compatibility on ATX and M-ATX platforms.

Fan Configuration:
SickleFlow 120 x 1 & SickleFlow 140 x 1
Allows 40mm RAM height for clearance and compatibility.

SickleFlow 140 x1
Concave heatsink design provides up to 70mm RAM compatibility.

Easy Mounting System

EASY MOUNTING SYSTEM

Exclusive All-In-One mounting design for easy installation


PREMIUM ALUMINUM BLACK TOP COVER
Black aluminum top cover offers a premium finish


DUAL TOWER HEAT SINK
Dual tower heatsinks provide twice the surface area for better cooling


6 HEAT PIPES WITH NICKEL PLATED BASE
6 heat pipes and nickel- plated base provides optimal coverage for exceptional cooling


DUAL SICKLEFLOW 140 FAN
Twin fans utilize Push-Pull setup for optimal airflow and pressure


RAM CLEARANCE OPTION
Optional 3rd SickleFlow 120mm fan included for necessary RAM compatibility and clearance


EASY MOUNTING SYSTEM
Exclusive All-In-One mounting design for easy installation

SKU: masterair-ma624-stealth Categories: , Tag:
PRODUCT NUMBER MAM-D6PS-314PK-R1
EXTERIOR COLOR Black
CPU SOCKET LGA2066, LGA2011-v3, LGA2011, LGA1200, LGA1366, LGA1156, LGA1155, LGA1151, LGA1150, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
HEAT SINK DIMENSIONS (L X W X H) 144.9 x 153.2 x 160 mm / 5.7 x 6 x 6.3 inch
HEAT SINK MATERIAL Aluminum Fins
HEATPIPES 6 Heat Pipes
FAN DIMENSIONS (L X W X H) 140 mm Fan – 140 x 140 x 25 mm / 5.5 x 5.5 x 1 inch, 120 mm Fan – 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
FAN QUANTITY 140 mm Fan – 2 PCS, 120 mm Fan – 1 PC
FAN LED TYPE N/A
FAN SPEED 140 mm Fan – 650-1400 RPM ± 5%, 120 mm Fan – 650-1800 RPM ± 5%
FAN AIRFLOW 140 mm Fan – 67 CFM (Max), 120 mm Fan – 62 CFM (Max)
FAN NOISE LEVEL 140 mm Fan – 10 ~ 27 dBA, 120 mm Fan – 8 ~ 27 dBA
FAN AIR PRESSURE 140 mm Fan – 2.25 mmH2O (Max), 120 mm Fan – 2.5 mmH2O (Max)
FAN MTTF 160,000 Hours
FAN POWER CONNECTOR 4-Pin (PWM)
FAN RATED VOLTAGE 12VDC
FAN RATED CURRENT 0.15A
FAN SAFETY CURRENT 140 mm Fan – 0.4A, 120 mm Fan – 0.37A
FAN POWER CONSUMPTION 1.8W
SERIES MasterAir
COOLER TYPE Air Cooler
Warranty 5 Years
Note *** Features, Price, Specifications are subject to change without notice.
